Description:
Industrial Grade MC65T-B3/MC65S-B3 6.5X-65X Trinocular Zoom Stereo Mechanical Microscope for Mobile Phone Welding Repair, High Quality Wide Angle Trinocular Stereo Microscope with HD Camera for iPhone Mobile Phone Maintenance
Mechanical Microscope D65T/D65S-B3 Industrial Trinocular Stereo For Phone PCB Soldering Repair
Product Features:
Good pixels, high resolution, deep field, long working distance makes operation convenient and comfortable, CPU can connect to external display
Large base plate, convenient for a series of jobs, won't lose parts, base plate size is
LED lights can adjust brightness, low power and safe, inner size is 60mm, input voltage is AC901-240V, output power is 4.5W, light color is white, number of bulbs is 56 pieces
Can be external work, the eyepiece is clearer, the operation is easier
Product Description:
High definition optical objective lens: made by precision craftsmanship, high definition coated objective lens, pure copper lens barrel; No glare, clear image, not letting go of every detail.
High field of view, FMC anti-reflective coating, high light transmission, high refractive index, 25mm lens diameter, clear imaging, no vignetting.
Interface: The newly upgraded electronic eyepiece, the image is clearer than the ordinary TV interface, and the field of view is wider.
Continuous zoom: optical system, continuous zoom with large magnification, the image is clear without distortion, and high definition; It can properly focus on the sample with large concave and convex area, so as to get three-dimensional image.
Focus knob: The focus gear bar is made of metal material, which is durable, and the precise focus with magnification makes the image clearer.
High-definition coated dust-proof mirror: Double-sided high-definition coated dust-proof mirror, which can effectively prevent dust, smoke, oil, etc. from getting inside and causing blurry images to ensure good light transmission without affecting the image.
High-brightness LED light: Using high-brightness LED cold light source, the color temperature is constant, close to natural light, and the brightness is stable. Equipped with a stepless adjuster, the brightness can be adjusted freely to provide adequate lighting for maintenance technicians.
Multi-angle use: add fixed rod height limiting accessories, which can fix the height, and the microscope can be rotated 360 degrees freely.
Product specifications:
Item Name: Trinocular Stereo Microscope
Brand: Mechanic
Model: D65T/D65S-B3
Magnification: 6.5x-65X
Eyepiece: WF10X/20mm high focus point wide field eyepiece (optional: 20X/20mm)
Viewing head: 45 degree inclined binocular head, 6.5x-65X continuous magnification objective, interpupillary distance 54-76mm, bilateral visibility adjustable
Working distance: 100mm (effective distance), select the auxiliary lens, which can be extended to 30mm-287mm
Focus bracket: the tightness of the focus wheel can be adjusted, the lifting range is 50mm
Base plate size: 195*256*20mm
LED light source: inner diameter 60mm, voltage: AC 90-240V, power: 4.5W, bulb: 56pcs
