CDEB Station
Soldering-Assistant
Improve your soldering quality in real time!
JBC innovates CDE station with Soldering Assistant, the first system that measures the delivered energy during the soldering process.
This station is deal for general soldering applications.
• Provides the best soldering quality thanks to JBC Intelligent Heat Management and, additionally, Sleep & Hibernation Modes that extend tip life till 5 times longer.
• Complete Tip Cleaning System with an antisplash membrane to keep the work area clean and integrated wiper to remove excess solder from the tip.
• Cartridge Holder and JBC Exclusive Cartridge Exchanger, that facilitates fast and safe cartridge changes.
• Possible connection to the JBC Fume Extractor (connector RJ12).
• Connectivity: datas download, software updates, traceability.
• Includes T245 General Purpose Handle that works with our C245 Cartridge Range.
CDE-9BQA
100 V
CDE-1BQA
120 V
CDE-2BQA
230 V
1
CDE Soldering Station
T245 General Purpose Handle
(cartridge not included)
Peak power
130 W - 23.5 V
Selectable temperature
90 to 450 ºC / 190 to 840 ºF
Temperature accuracy
±3%
ESD safe
Meet ANSI/ESD S20.20-2021
Equipotential bonding
Connection to EPA
Tip-to-ground resistance
<2 ohms
Tip-to-ground voltage
<2 mV RMS
USB-A
Graphics and profiles
USB-B
FAE / Robot connector
Remote control or FAE Fume Extractor connection
Peripheral connector
For MNE
WEIGHT AND DIMENSIONS
Control Unit
170 x 176 x 145 mm / 2.94 kg.
6.69 x 6.93 x 5.71 in / 6.48 lb.
Package
234 x 234 x 258 mm / 3.54 kg.
9.21 x 9.21 x 10.16 in / 7.80 lb.
