维修专用显微镜
| ZS7045 | 标配（无辅助物镜） Standard (No auxiliary Lens) | 带有辅助物镜 Auxiliary Lens | ||||||||||
| 0.3X | 0.5X | 0.75X | 1.5X | 2X | ||||||||
| 目镜 Eyepiece | 工作距离 100mm Working Distance 100mm | 工作距离 287mm Working Distance 287mm | 工作距离 165mm Working Distance 165mm | 工作距离 117mm Working Distance 117mm | 工作距离 45mm Working Distance 45mm | 工作距离 30mm Working Distance 30mm | ||||||
| 放大倍率 Magnification | 视场 View | 放大倍率 Magnification | 视场 View | 放大倍率 Magnification | 视场 View | 放大倍率 Magnification | 视场 View | 放大倍率 Magnification | 视场 View | 放大倍率 Magnification | 视场 View | |
| WF10X20mm | 7X | 28mm | 2.1X | 70.8mm | 3.5X | 52.1mm | 5.3X | 35.1mm | 10.5X | 19mm | 14X | 13.5mm |
| 45X | 4.3mm | 13.5X | 12.1mm | 22.5X | 8.4mm | 33.8X | 5.6mm | 67.5X | 3mm | 90X | 2.2mm | |
| WF15X15mm | 10.5X | 20.6mm | 3.2X | 55mm | 5.3X | 40.2mm | 7.9X | 27.6mm | 15.8X | 13.5mm | 21X | 10.2mm |
| 67.5X | 3.2mm | 20.3X | 10.2mm | 33.8X | 6.4mm | 50.6X | 4.3mm | 101.3X | 2.2mm | 135X | 1.7mm | |
| WF20X10mm | 14X | 13.1mm | 4.2X | 38.4mm | 7X | 26.9mm | 10.5X | 17.8mm | 21X | 9.5mm | 28X | 6.5mm |
| 90X | 2.1mm | 27X | 6.3mm | 45X | 4.3mm | 67.5X | 2.9mm | 135X | 1.5mm | 180X | 0.8mm | |
| WF25X9mm | 17.5X | 14.5mm | 5.3X | 40.7mm | 8.8X | 30mm | 13.1X | 19.2mm | 26.2X | 8.5mm | 35X | 7.1mm |
| 112.5X | 2.2mm | 33.8X | 6.3mm | 56.3X | 4.3mm | 84.4X | 3.1mm | 168.8X | 1.2mm | 225X | 1mm | |
| WF30X8mm | 21X | 11.1mm | 6.3X | 32.4mm | 10.5X | 22.8mm | 15.8X | 15mm | 31.5X | 7.5mm | 42X | 5.3mm |
| 135X | 1.9mm | 40.5X | 5mm | 67.5X | 3.5mm | 101.3X | 2.3mm | 202.5X | 1.2mm | 270X | 0.9mm | |
| 观察头 Observation head | 45°倾斜，360°旋转，瞳距54---76mm；双边视度调节±5屈光度 45°decline, 360°rotate, Pupil distance 54---76mm; Bilateral visual adjustment±5 |
| 铰链式双目 Hinged binocular | |
| 目镜 Eyepiece | 标准配置：WF10X20，高眼点广角型目镜，为佩戴眼镜的观察者提供方便 Standard WF10X20, High angle wide angle eyepiece, provide convenience for observers wearing glasses |
| 可选目镜 Optional eyepiece | WF10X20mm，WF15X15mm，WF20X10mm，WF25X9mm，WF30X8mm |
| 放大倍数 Magnification | 标准配置：7X---45X，选配目镜和辅助物镜可扩展至2.1X---270X，连续变倍 Standard 7X---45X, Optional and auxiliary lenses can be extended to 2.1X---270X, Continuous doubling |
| 物镜 Objective | 0.7X---4.5X连续变倍，物镜变倍比1：6.4，确保像面齐焦性 0.7X---4.5X Zoom Range, objective magnification ratio 1：6.4, Ensure image alignment |
| 辅助物镜 Auxiliary Lens | 0.3X，0.5X，0.7X，1X，1.5X，2X可选配 For option |
| 工作距离 Working Distance | 100mm |
| 调焦托架 Focus arm | 内径76mm，立柱孔径32mm 76mm Diameter, 32mm pole size |
| 底座 Base | STL2双臂万能万向支架（标配），可配选其他底座，详见底座系列图 STL2 Universal Bracket with Two Arms, Other base can be selected, See the base series for details |
| 照明 Illumination | 可选配各种LED环形灯，详见LED光源系列图 Optional LED Illumination, See LED light source series diagram for details |
